THE SAKAI TW504 SMOOTH DRUM ROLLER - A MASTER IN ITS OWN CLASS!

Sakai is the leading manufacturer of vibratory compaction equipment in the world, building and shipping more vibratory soil compactors and asphalt rollers than any other equipment manufacturer. Sakai is also a pioneer of new technology – introducing the world's first vibratory pneumatic tire roller.

 Observing the Sakai TW504 on site one would be very impressed with its maneuverability and compactive capabilities. This equipment is ideal for small to medium tonnage jobs and is great for turns because the rear tires will not damage the curb.

 This machine is perfect for the following applications:-

  • Road shoulders, ramps and widening
  • Road maintenance
  • Parking lots and driveways
  • Municipal and county roads
  • Tennis and basketball courts

The following features of the TW504 invites the contractor to a test drive :-

Proven Compactive Performance

  • Roller compactive force reaches target density in less number of roller passes. Provides higher centrifugal force and amplitude

Operator Comfort and Safety

·         Includes Sakai's durable dual rubber isolation system between the drum and operator deck.

Low Operating Costs

·         Sakai's new Eco compaction mode (ECM),  reduces fuel consumption up to 20%, while maintaining compactive performance.

Excellent Traction

·         Built in safety features prevent accident starting, starts only when the forward, neutral and reverse lever is in the neutral position and press down the parking brake switch.

Technical Specifications of the Sakai TW504:-

Drum

  • Tires # (size): 4 (10.5 / 80-16-6PR)
  • Size (w x d): 51 X 31 ins | 1,300 X 800 mm

Operating

  • Weight: 7,740 lbs | 3,510 Kg

Vibration (Front Drum)

  • Frequency: 3,100 vpm | 52 Hz
  • Centrifugal Force (L / H): 5,955 / 7,710 lbs | 26.5 / 34.3 kN
  • Nominal Amplitude (L / H): .012 / .016 ins | .30 / .40 mm

Engine

  • Make & Model: Kubota (Final Tier 4) D1703-M-DI-EF03
  • Horsepower: 24 Hp | 18.2 kW

Braking

  • Systems: Hydrostatic Service Brake + SAHR Parking Brake + Combined Footbrake
  • Fluids
  • Fuel Capacity: 13.2 gal | 50 lit
  • Sprinkler Capacity: 82 gal | 310 lit

Rayneau Rentals & Sales is proud to carry a large selection of Sakai compaction equipment.  We have Sakai asphalt and dirt rollers available to buy or rent.

Give us a call at (758) 450 7368 or drop by today to see how we can help you complete your next big project. We are located at Vide Bouteille along the Gros Islet Highway.
